MIL-PRF-87260B(USAF)
APPENDIX A
ELECTROSTATIC
PROBE (27.5 INCHES LONG)
1-2
INCH
GAP
F
F
F
O
O
O
A
A
A
M
M
M
TANKS ARE
22-1/2 INCHES
IN DIAMETER
AND ARE 32
INCHES LONG
TANK WITH 4 INCH
FULLY PACKED TANK
DIAMETER HOLE
CUT THROUGH
CENTER OF FOAM
FIGURE A-2. Schematic of two different impingement scenarios.
